Size: 5.48 MB
Format: PDF
Language: English
Brand: Tesla
Type of Machine: Automotive
Type of Manual: Wiring Diagram
Model: Tesla Model X LHD and RHD
Date: to 01.2023
Number of Pages: 62 Pages
Contents:
Table of Contents
Vehicle Controller Layout, Front
Vehicle Controller Layout, Side
Air Suspension
Audio – A2B, Microphones and Radio
Audio – External Amp
Audio – MCU
Braking and Stability
Cabin Overhead
CAN – Body
CAN – Chassis
CAN – Falcon
CAN – Low Power
CAN – Party
CAN – Vehicle
Center Console
Diagnostics
Doors – Front Left – Door Controller
Doors – Front Left – Left Controller
Doors – Front Right – Door Controller
Doors – Front Right – Right Controller
Doors – Rear (Falcon) – Pinch Sensors
Doors – Rear (Falcon) – Strut Actuators
Doors – Rear (Falcon) – Ultrasonics
Doors – Rear (Falcon) Left – All
Doors – Rear (Falcon) Right – All
Drive Inverter – Front
Drive Inverter – Rear
Driver Assistance
Exterior Illumination – Front
Exterior Illumination – Rear
Frunk Actuators / Sensors
Grounding – Body Left
Grounding – Body Right
Grounding – Cabin – Falcon Doors
Grounding – Frunk
Grounding – Liftgate
HV – Battery Pack
HV – Battery Pack Interface, HVIL
HV – Chargeport
HVAC – Cabin Climate 1/2
HVAC – Cabin Climate 2/2
HVAC – Powertrain and Battery
HVAC – Thermal Bar
HVAC Case
Instrument Panel
Liftgate Actuators / Sensors
Parking Aids
Power Distribution – Main
Restraints Control 1/2
Restraints Control 2/2
RF / Special Cables
Seats – 1st Row – Body Controller
Seats – 1st Row – Seat Controller
Seats – 2nd Row – 60/40 Fold
Seats – 2nd Row – Monopost
Seats – 2nd Row – Power
Seats – 3rd Row
Security
Steering, Display Actuators
Trailer Interface
Windshield
